Description
The MSI PRO B760M-P DDR4 is a business-oriented Micro-ATX motherboard designed to support Intel’s 12th, 13th, and 14th Gen processors. It offers essential features for home and office systems, including support for high-speed DDR4 memory, PCIe 4.0, dual M.2 slots, and multiple display outputs. With its robust build quality and efficient design, it’s an excellent choice for users seeking stability and performance without unnecessary extras.
Key Features
-
Supports IntelÂŽ Coreâĸ 14th, 13th, and 12th Gen processors, IntelÂŽ PentiumÂŽ Gold, and CeleronÂŽ processors for LGA 1700 socket
-
Supports DDR4 Memory, Dual Channel DDR4 4800+MHz (OC)
-
Core Boost: With premium layout and digital power design to support more cores and provide better performance
-
Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability, and compatibility
-
Lightning Fast Experience: PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
-
Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability, and strength
-
Audio Boost: Reward your ears with studio-grade sound quality for the most immersive experience
-
Frozr AI Cooling: Detect CPU & GPU temperatures and automatically adjust system fan duty to a proper value
| MSI PRO B760M-P DDR4 Micro-ATX Motherboard – Specifications | |
|---|---|
| Brand | MSI |
| Chipset | Intel B760 |
| Color | Black PCB with grey accents |
| Connectivity | Realtek RTL8111H Gigabit LAN, USB 3.2 Gen 2 Type-C, USB 3.2 Gen 1, USB 2.0, HDMI, DisplayPort, VGA |
| Form Factor | Micro-ATX (243.84mm x 243.84mm) |
| CPU Support | IntelÂŽ Coreâĸ 14th, 13th, and 12th Gen, PentiumÂŽ Gold, and CeleronÂŽ processors |
| Socket Type | LGA 1700 |
| Memory Support | 4 x DDR4 DIMM slots, up to 128GB, Dual Channel, up to 4800 MHz (OC) |
| Expansion Slots | 1 x PCIe 4.0 x16 (with Steel Armor), 2 x PCIe 4.0 x1 |
| Storage | 2 x M.2 Gen4 x4 64Gbps slots, 4 x SATA 6Gbps ports |
| Display Outputs | 1 x HDMI 1.4 (4K@30Hz), 1 x DisplayPort 1.4 (4K@60Hz), 1 x VGA |
| Audio | 8-Channel (7.1) HD Audio with Audio Boost |
| LAN | Realtek RTL8111H Gigabit LAN |
| Rear USB Ports | 1 x USB 3.2 Gen 2 Type-C, 3 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 |
| Internal Connectors | 2 x USB 2.0 headers, 1 x USB 3.2 Gen 1 header |
| Cooling | Frozr AI Cooling, M.2 Shield Frozr, EZ Debug LED |
| BIOS | Click BIOS 5 |
| OS Support | Windows 11/10 64-bit |
